SLESA-U9 DMX Live control and Stand Alone controller

Product Description

The SLESA-U9 is the perfect product for applications with less than 256 DMX channels. It offers a standalone memory with a maximum of 218 steps (256 channels) as well as 8 ports for dry contacts triggering.
Because of its simplicity this interface is extremely reliable. It is also the perfect product for integrators or manufacturers because of its multiple versions: with or without block connector, power supply…

Product Specifications

Package:Interface, cdrom, usb cable
OS Requirement:Mac OSx 10.6/10.7/10.8 - Windows XP/VISTA/SEVEN/8 32/64 bits and USB 2.0
Colors :Blue, Orange, Gray, Green, Marine, White, Red
Connections:XLR3, mini USB, 1 HE10
Power :Power From 5V to 5.5V DC (AC/DC adapter in option, ref: POWER1_EU)
Certifications:EC, EMC, ROHS, ETL, UL (some are in progress)
Interface :79x92x43 mm 90g
Package :140x135x50 mm 290g
Use :Environement IP20 Temperature 0ºC to 50ºC
Buttons :2 buttons to change scene (previous/next) + 1 button to change dimmer

Spec Sheet

Product Application

This product is great for:

  • Lighting control
