PTSL-RGB-18-Luxor LED Light Strips

Contact Prism to purchase.

Description

RGB LUXOR HI-POWER LED LIGHT STRIP

RGB Luxor Hi-Power LED Light Strips are the perfect lighting solution for backlit graphics. Using precision optical lenses, the Luxor LED light controls the beam exactly where it has to be, producing a bright white light evenly distributed throughout the graphic area.

No need to fill the back panel with lights, as RGB Luxor LED lights are so efficient, only two inside walls of a light box are typically required for a standard lightbox. Each RGB Luxor strip uses only 24 Watts of energy and can give you over 16 million color choices. From a simple RGB controller to DMX theatrical lighting control, the RGB Luxor was designed to work with both formats. A full size Luxor Strip is 18” long and uses 6 Hi-Output CREE RGB LEDs behind precision Fresnel Dual optical Lens with concentric grooves to create ideal internal light distribution. Prism also offers a 3 Hi-Output RGB Luxor that is only 9” long

RGB Luxor LED Light Strips can be used for single-sided or double-sided graphics, tension fabric or acrylic panels. Each Luxor Strip includes Prism Quick-Connect tails at each end and you can link up to 5 strips in a row. Prism offers 2-point and 6-point splitters and extension cables, along with stocking and custom built power supplies, for a complete turn-key light box lighting solution. There are no limitations when using Luxor Hi-Power LED Light Strips, White light or RGB Light for light box applications.

A Signature LED lighting product designed, engineered and built by Prism Tradeshow Lighting

PRISM ORIGINAL SERIES

Product Specifications

•Light Source –CREE High Power RGB LED
•LED Quantity:6PCS
•DC IN Voltage: DC24V ±0.5V
•LED Source Power:24W
•Power Consumption: 24W ±5%
•LED CCT: RGB
•Lens Angle: 10*80 angle
•Maximum five units to be interconnected.
•Material: Aluminum PCB and Extrusion
•LED module dimension: 450*25*16mm
•Case dimension: 475*35*20mm

Spec Sheet
